MARINE

No power-off when duel with overlord

Support over 8 hours of use.

Best accessory for PS4 controller!

Your loyal personal Marine won't let you down.

日本の方は Columbus Circle社までお問い合わせください。

For Japan, please contact at Columbus Circle.

Overview





With “MARINE”, you can use PS4 controller to play your favorite games wirelessly on PS4, PS3, Switch, Android, PC and Mac, and 4 removable extra buttons give you the flexibility to customize the controller.

You can say goodbye to “out of power” when faced with big challenges, “MARINE” will release the full potential of your PS4 controller to rock your gaming experience!

Features





  • Support PS4, PS3, Switch, Android, PC and Mac
  • Wireless Control
  • Support Turbo and Remap
  • 4 Extra Customizable buttons
  • Replaceable 18650 Battery
  • Support Motion Control (for PS4/SW)
  • Audio Function (for PS4)

Video

Image AD:

Tutorial:

More Videos

Install

Click Here to download "Complete User Manual"

Instructions

PS4/PS3/NS mode



Wired Connection

Connect directly to MARINE and PS4/PS3/NS consoles with Micro-USB cable.

Wireless Connection

  1. Turn the knob to PS4/PS3/NS mode and press the BROOK-Key to activate. Please confirm that the LED on MARINE is displayed in blue/cyan/orange.
  2. For first time use, please operate by wired connection.

Support Features:



PS4

PS3

NS

Wired control

Wireless control

Audio function

(Wired)

Audio function

(Wireless)

Motion control

Turbo & Remap



=Support、╳=Not Support














































Android/PC/Mac mode



Wired Connection

When knob is in Ad/PC/OS mode, connect MARINE to Android device/PC/Mac (iOS device) with Micro-USB cable and proper OTG connector.

Wireless Connection

  1. It has to be paired via Bluetooth for first time use. After pairing is completed, you can use it wirelessly. The pairing method is as the followings:
    1. Press and hold the BROOK-Key for 2 seconds to enter the pairing mode, the LED will flash red and blue alternately.
    2. Turn on Bluetooth on Android/PC/Mac, search for “P4 Battery Pack” in Android Mode/ “P4 Battery Pack” in PC Mode/ “Wireless Controller” in Mac Mode, and then click Connect.
    3. When the connection is successful, the LED will appear as green/white/yellow.
  2. For future use, make sure the knob is in Ad/PC/OS mode, and press the BROOK-Key to activate MARINE to reconnect to the console. Please confirm that the LED on MARINE is displayed in green/white/yellow.

Support Features:



Android

PC

Mac

Wired control

Wireless control

Audio function

(Wired)

Audio function

(Wireless)

Motion control

Turbo & Remap

=Support、╳=Not Support

Connect to PS4:

Connect to PS3:

Connect to NS:

Connect to diffrent consoles(PS4/PS3/NS)




Connect to Android:

Connect to iOS 13:

Functions

Turbo Setting

Turbo function available buttons:╳、○、□、△、L1、R1、L2、R2、L3、R3 and the 4 paddles on MARINE. In the following description, these buttons are referred as FB, the controller will vibrate when setting:



Step 1. Enter the Turbo Setting Mode:

Press Share & PS Key, MARINE’s LED will dim.

Step 2. Choose FB:(EX: to set turbo function

Hold down Share, then press ╳.

Step 3. Complete the Turbo Setting Mode:

Release all buttons then press Option.

The controller will vibrate once strongly.

To set another button, repeat Step 2.

Step 4. Exit the Turbo Setting Mode:

Press PS Key to save the settings and exit setting mode.

If it’s not set successfully, please check step 3.



Cancel all turbo settings:

After entering the turbo setting mode by pressing the Share & PS key, press and hold Share + Option, then press the PS Key to clear all settings. This will clear all turbo settings, but will not affect the remap settings.

When all settings are canceled, the controller will vibrate three times strongly.

Remap Setting

Remap function available buttons:╳、○、□、△、Up、Down、Left、Right、L1、R1、L2、R2、L3、R3 and the 4 paddles on MARINE. In the following description, these buttons are referred as FB, the controller will vibrate when setting:



Step 1. Enter the Remap Setting Mode:

Press Option & PS Key, MARINE’s LED will dim.

Step 2. Choose FB: (EX: to do + function)

Press △.

Step 3. Choose Remap button:

Hold down Share, then press +○.

Step 4. Complete the Remap Setting Mode:

Release all buttons then press Option.

To set another button, repeat Step 2 to 4.

Step 5. Exit the Remap Setting Mode:

Press PS Key to save the settings and exit setting mode.

If it’s not set successfully, please check step 4.



Cancel all Remap settings:

After entering the Remap Setting Mode by pressing the Option & PS key, press and hold Share + Option, then press the PS Key to clear all settings. This will clear all remap settings, but will not affect the turbo settings.

When all settings are canceled, the controller will vibrate three times strongly.



Note:

The 4 paddles on MARINE can be mapped as other buttons, but not vice versa. For example, you can map a paddle as "╳+○", but you can't map ○ to the paddles.

Button Configuration

PS4

PS3

SW

Android

PC

macOS

UP

UP

UP

UP

UP

UP

Down

Down

Down

Down

Down

Down

Left

Left

Left

Left

Left

Left

Right

Right

Right

Right

Right

Right

B

A

A

A

A

B

B

B

Y

X

X

X

X

Y

Y

Y

SHARE

SELECT

-

SELECT

Back

Back

OPTIONS

START

+

START

Start

Start

Lx

Lx

Lx

Lx

Lx

Lx

Ly

Ly

Ly

Ly

Ly

Ly

Rx

Rx

Rx

Rx

Rx

Rx

Ry

Ry

Ry

Ry

Ry

Ry

L1

L1

L

L1

L1

L1

R1

R1

R

R1

R1

R1

L2

L2

ZL

L2

L2

L2

R2

R2

ZR

R2

R2

R2

L3

L3

LTSB

L3

L3

L3

R3

R3

RTSB

R3

R3

R3

PS

PS

Home

Home

Home

Home

Touch-Pad



Touch-Pad+Key



Capture




PS4

PS3

SW

Android

PC

macOS

Brook-Key

SHARE

PS

Capture

Home

Home

Back

Notice

  1. The Remap Setting in each Mode will be memorized. For example: you make a Remap Setting in PS4 mode, then switch to NS Mode. The next time you switch back to PS4 mode, the Remap Setting in PS4 mode still remains.
  2. The default of Backup Mode has no function currently. It is reserved for possible future product upgrades.
